Ex9UEP1+2 6.25 2P 1000
Ex9UEP1+2 6.25 2P 1000
| Brand | NOARK |
|---|---|
| EAN Code | 8592765117519 |
| Mounting method | DIN rail (top hat rail) 35 mm |
| Width in number of modular spacings | 2 |
| Construction size | 2 modular spacing |
| Max. conductor cross section solid (solid, stranded) [mm²] | 25 |
| Max. conductor cross section flexible (fine-strand) [mm²] | 25 |
| With remote signalling contact | No |
| Integrated backup fuse | No |
| Signalling at the device | Optic |
| Power loss [W] | 0.1 |
| Number of poles (total) | 2 |
| Nominal voltage DC [V] | 1000 |
| System configuration DC | Yes |
| System configuration IT | No |
| System configuration TN | No |
| System configuration TN-C | No |
| System configuration TN-C-S | No |
| System configuration TN-S | No |
| System configuration TT | No |
| System configuration other | Yes |
| Lightning impulse current (10/350 µs) [kA] | 6.25 |
| Max. continuous voltage DC [V] | 1000 |
| Test class | Type 1 + 2 |
| Exhausting | No |
| Energy-coordinated protection effect with regard to the terminal equipment | No |
| Warranty | 5 Years |
