DC Rotary switch disconnector Ex9IR50-26/15/PV2/2
DC Rotary switch disconnector Ex9IR50-26/15/PV2/2
| Brand | NOARK |
|---|---|
| IP | 20 |
| EAN Code | 8592765135087 |
| Color | Grey |
| Number of poles (total) | 2 |
| Version as main switch | Yes |
| Version as maintenance-/service switch | Yes |
| Version as safety switch | No |
| Version as emergency stop installation | No |
| Version as reversing switch | No |
| Number of switches | 1 |
| Rated operating voltage [V] | 1500 |
| Rated permanent current Iu [A] | 26 |
| Rated short-time withstand current lcw | 0.7 |
| Device construction | Built-in device fixed built-in technique |
| Suitable for ground mounting | No |
| Suitable for front mounting 4-hole | No |
| Suitable for front mounting center | Yes |
| Suitable for distribution board installation | Yes |
| Suitable for intermediate mounting | Yes |
| Type of control element | Door coupling rotary drive |
| Interlockable | No |
| Type of electrical connection of main circuit | Cable clamp |
| Warranty | 5 Years |
