Surge Protective Device Ex9UE2 20 2P 275

Brand	NOARK
IP	20
EAN Code	8592765033529
Color	Grey
Mounting method	DIN rail (top hat rail) 35 mm
Width in number of modular spacings	2
System configuration	TN-S, TT
Type of poles	2
Nominal discharge surge current (8/20) [kA]	20
Nominal voltage AC [V]	275
Max. continuous voltage AC [V]	275
Voltage protection level L-N [kV]	1.4
Short-circuit-proof	Yes
Construction size	2 modular spacing
Max. conductor cross section solid (solid, stranded) [mm²]	35
Max. conductor cross section flexible (fine-strand) [mm²]	35
With remote signalling contact	No
Integrated backup fuse	No
Signalling at the device	Optic
Category type 2	Yes
Power loss [W]	0.1
Warranty	5 Years

SKU: 103351 Category: NOARK
